Aquamiser+ Modular

A full-featured and affordable solution for tight spaces and bulkheads.

  • Traditional Watermaker providing Analog pressure and flow readings
  • Exclusive AQ3 Control System with staged starting of motors
  • Fully automated programmable Fresh Water Flush system

The Aquamiser+ Series is a full-featured affordable solution that meets your water making needs. Its advanced programmable settings, remote display capabilities and included Fresh Water Flush system make it the clear choice amongst boaters who prefer a hands-on approach to Watermaker operation.

Aquamiser+ Modular Specs

Available Output
GPD
250 / 500 / 600 / 800 / 1,200 / 1,800
Electrical Requirements
HP
1.5 / 1.5 / 1.5 / 1.5 / 2.5 / 2.5
KW
1.52 / 1.52 / 1.52 / 1.52 / 2.29 / 2.29
VAC
120 / 220
Phase
1
HZ
50 / 60
  • Get Aquamiser+ Modular Spec Sheet

Overview

The FCI Aquamiser+ Series offers the latest in engineering solutions and trouble-free operation. It’s the dependable solution for boaters who prefer an active approach to operating their Watermaker.

The exclusive AQ3 Control System allows remote display capability, and programmable settings with a fully automated Fresh Water Flush system. Scheduled flushes, once a week or more frequently, will help maintain and keep your Watermaker fresh and ready for your next voyage.

With outputs of 250-1,800 GPD, and available in both Framed or Modular configurations, this series has a solution for your purified water needs. In addition to remote monitoring and control capabilities, Commercial Pre-filters are standard on 1,200 and 1,800 GPD units; and, a no-cost upgrade for lower output systems when chosen at the time of order.

The Aquamiser+ marine reverse osmosis systems are also DTS+ (Dockside Treatment System) compatible. FCI DTS+ units allow you to create purified drinking water, and enjoy spot-free wash-downs from your dockside municipal source at minimal cost without compromising your seawater membranes. The FCI DTS+ add-on component works in-line while utilizing your existing Aquamiser+ pump and control system.

Read more on Why FCI is The Clear Choice for reliability, engineering and technical support.

Typical Sea Water Conditions

Temperature
77° F / 25° C,
TDS
32,000,
Pressure
825 PSI

Components & Variations

Aquamiser+ Modular

Control Panel
Width7.65"
Depth6.25"
Height9.50"
Flow Panel
Width11.50"
Depth7.35"
Height15.15"
Fresh Water Flush
Width9.10"
Depth6.00
Height12.25"
HP Pump
Width18.80"
Depth9.80"
Height10.50"
Pre-Filter
Width13.50"
Depth5.30"
Height12.50"
LP Pump
Width7.30"
Depth16.00"
Height10.80"
250-500 PV Assembly
Width28.00"
Depth4.00"
Height8.25"
600-1800 PV Assembly
Width47.50"
Depth4.00"
Height12.75" (3 vessels)
Standard Features
  • 316SS HP Pump
  • 316SS Motor Shaft
  • Vibration isolation mounts
  • Staged starting of motors
  • Timed start-up (Prime, Init, Run)
  • TDS monitoring of product water
  • Automatically diverts water to the product tank below 500 PPM
  • Programmable automatic Fresh Water Flush with convenient one-touch button for manual operation
  • Brine and Product Flow Meters
  • High and Low Pressure Shutdown
  • Superior Customer Support
  • 200 page complete Operation Manual with exploded views and operational instructions
Features with Remote Display
  • Remote system control up to 150’ away
  • Digital readout of product TDS
  • Automatic tank level controls
  • Programmable set points for all critical settings to allow for variances in operation
Optional Equipment / Accessories
  • Dockside Treatment System (DTS)
  • Filter Replacement Kit
  • Pocket PPM Meter
  • Ultra-Violet Sterilizer
  • Remote Display

Available Accessories

600-1,850
GPD

DTS+

Replacement Parts

AQ3 Remote
